LLM Observability with Splunk and OpenLLMetry

Collecting and analyzing LLM traces in Splunk Observability Cloud can be achieved by configuring the TRACELOOP_BASE_URL environment variable to point to the Splunk OpenTelemetry Collector OTLP endpoint.

Have the Collector run in agent or gateway mode and ensure the OTLP receiver is configured, see Get data into Splunk Observability Cloud.

receivers:
  otlp:
    protocols:
      grpc:
        endpoint: "0.0.0.0:4317"
      http:
        endpoint: "0.0.0.0:4318"

Secondly, ensure the OTLP exporter is configured to send to Splunk Observability Cloud:

exporters:
  # Traces
  sapm:
    access_token: "${SPLUNK_ACCESS_TOKEN}"
    endpoint: "https://ingest.${SPLUNK_REALM}.signalfx.com/v2/trace"
    sending_queue:
      num_consumers: 32

Thirdly, make sure otlp is defined in the traces pipeline:

  pipelines:
    traces:
      receivers: [jaeger, otlp, sapm, zipkin]
      processors:
      - memory_limiter
      - batch
      #- resource/add_environment
      exporters: [sapm]

Finally, define the TRACELOOP_BASE_URL environment variable to point to the Splunk OpenTelemetry Collector OTLP endpoint:

TRACELOOP_BASE_URL=http://<splunk-otel-collector>:4318
